PAGIS RISF : ⑤
Main benefits
High-levels of security gives the best possible peace of mind
Needs almost no maintenance
Attractive appearance enhances any home
Retains heat superbly
Keeps out cold, damp and draughts
USP: Four-chamber sash gives rigidity and improves thermal performance
20mm air gap in sealed units Pilkington K glass as standard BS6206A toughened safety glass as standard in high risk areas (optional elsewhere) Stainless steel shoot-bolt mechanisms lodge into solid metal keeps, which are secured through frame into galvanised steel reinforcement Galvanised steel reinforcement within frame adds to rigidity and security Off-set handle with key-operated deadlock is easy and comfortable to use. Locking position for ventilation Multi-point bi-directional locking bolts exceed BS657950 by 50% Outer weatherproof seal prevents water getting in (EPDM) Bottom sheet bolt Received 230215
USP: Tough, interlocking hinge-side security brackets resist forced entry by would-be intruders. Exceeds BS7950 by 50%
Cross-section shows how hinge-side security brackets interlock Long-lasting 'slim-line' glazing gasket (EPDM) PVC-U trims enhance appearance Inner weatherproof seal keeps out draughts (EPDM) Galvanised steel reinforcement
USP: 15 00194
DEPARTMENT OF INFRASTRUCTUREOptional PLANNING and BUILDING
Easel sight-lines
Egress hinge
Classic sash (unique to Everest)
White glazing gasket
Handles in gold, silver or white
Ventilated head
Windowboards
Leaded glass
Coloured glass
Internal Georgian bars
