NEW TWO STOREY EXTENSION \& ATTIC CONVERSION AT 34 BALLANOA MEADOW, SANTON
Existing Site
34 Ballanoa Meadow, Santon is a two storey, semi-detached residential property with a pitched roof within the Ballanoa Meadow development. The property is located at the head of the cul-de-sac and is the higher of two properties due to the contours of the site. There is a hardstanding to the side of the property that provides off road parking and access to the rear garden.
Proposed Extension
The proposals involve the construction of a two storey extension to the side of the property and conversion of the attic space into a bedroom. A number of similar extensions have been undertaken within Ballanoa Meadows and we include photographs below for reference.
The extension will be finished in suitable materials to match the existing residential property.
The existing hardstanding to the front of the property is to be increased in width to accommodate two car parking spaces with a pedestrian path to the front door.
Examples of Similar Extensions in Ballanoa Meadow
Two storey extension to the side of 26 Ballanoa Meadow
A photograph showing the side elevation of a two-story cream-colored house with a brick base, featuring a driveway and a parked red car.
Two storey extension to the side of 26 Ballanoa Meadow {{image:218848}}
Two storey extension to the side of 39 Ballanoa Meadow
DISTRIBUTION
DRAWING REGISTER
19/00350
CJ DESIGN LIMITED
10 Ballaterson Road
Peel,
Isle of Man, IM5 1BJ
Mobile (07624) 426277.
Email: [email protected]
CLIENT
Mr Marek Hudec & Mrs Katarina Kothajova
PROJECT NAME
34 Ballanoa Meadow, Santon
PROJECT NUMBER
2018/56
DRAWINGS
Planning, Building Regulations & Tender
22
25
TYPE :
03
03
SHEET No :
One
19
19
DRAWING DESCRIPTION
SIZE
DRAWING NO AMENDMENTS
Location Plan
A3
01
\
Site & Floor Plans - As Existing
A1
02
\
\
Floor Plan and Elevations - As Proposed
A1
03
\
\
DISTRIBUTION
NUMBER OF COPIES
CLIENT
1
Quantity Surveyor's
Mechanical Engineer
Contractor
Planning Supervisor
Planning Department
4
Building Control Dept.
Fire Officer
Other
Information
1
Comments
2
Approval
3
Construction
4
3
3
Tender
5
Contract
6
d = disk e = Email p = paper copies
e
p
Isle of Man
A black and white site plan showing property boundaries, roads, and building footprints in a rural area, with a specific plot highlighted in red.
19/00350
Department: Isle of Man Government
Division/Office: DEFA
Case Reference:
Date: 22/03/2019
Reproduced from the IxM Survey map with the permission of the Department of Infrastructure & Crown Copyright 2015. Unauthorized reproduction infringes Crown Copyright and may lead to prosecution or civil proceedings.
Scale: 1:2,500
Scale bar: 50
No. 60
