C o n s u l t a n c y D e s i g n P l a n n i n g M a n a g e m e n t B u i l d Planning & Building Control Directorate First Floor Murray House Mount Havelock Douglas Isle of Man IM1 2SF 24th September 2021 Ref: JTM2119/P/01 To whom it may concern,
RE: Planning Application for the Proposed Renovation, Extension & Garage Replacement: 5 Somerset Road, Douglas, Isle of Man. IM2 5AE.
Please find enclosed digital copies of the required Planning Application, Fee and Drawings:
JTM2119-P-00 - Location Plan & Existing & Proposed Site Plan
JTM2119-P-01 - Existing Floor Plans
JTM2119-P-02 - Existing Elevations
JTM2119-P-03 - Proposed Floor Plans
JTM2119-P-04 - Proposed Elevations
JTM2119-P-05 - Garage Visibility Splay Appendix A - Existing Photographs
I trust that the above and enclosed are satisfactory however should you require any further information then please do not hesitate to contact me.
Regards
John McCarrick
BA (Hons), PGCert, PGDip, BARCH, PGDip ARCH (LMU)
RIBA Chartered Architect C.c. Mr & Mrs S. Pratt
Appendix A: See Drawings JTM2119-P-01 & JTM2119-P-03
1. Demolition of Existing Garage: The existing garage is too small for a modern vehicle and will be replaced with a larger garage with for two cars, electric charging points, bin and bicycle storage.
2 & 3. Some reconfiguration will be undertaken to ensure that the rear and side walls can accommodate the new flat roof.
4. Existing WC & Utility Annex to be demolishd and rear wall opened to provide extra internal living space and angled wall to be removed.
A photograph showing the front exterior of a small, grey single-story outbuilding or garage with a gable roof and a decorative metal screen. A blue plastic tub sits on the paved area in front of the structure.A photograph showing a paved courtyard area between a white residential building and a grey single-story outbuilding with a weathered gate nearby.A photograph showing a high white rendered wall in the foreground and a traditional white building with sash windows in the background.A close-up photograph showing a weathered, dark wooden door set into a rough, light-colored wall with vegetation growing at the base and top.A photograph showing a small, single-story grey building with a slate roof and a small window. A clothesline is strung across the front, and a wheelie bin is visible to the left.An interior photograph showing a white refrigerator standing next to a white paneled door with a gold handle against a textured beige wall.
5. Existing external wall to be opened to accommodate proposed covered and enlarged Kitchen/Dining Area and esier access from the hallway.
6. Erection of New Sun Room with Roof Lantern & Replacement of Existing Window with a Glazed Door.
7. Installation of New WC & Sink to under stairs. Fabric of staircase to be maintained with internal reconfiguration only.
Interior photograph of a residential kitchen featuring white wall cabinets, a wooden shelving unit, and a window.Interior photograph of a residential kitchen featuring white cabinetry, black countertops, and stainless steel appliances.A photograph showing the rear exterior of a white terraced building with a bay window, featuring a paved patio area, planters, and a small outbuilding in the background.A close-up photograph of the grey exterior facade of a terraced building, showing white window frames, a drainpipe, and a small plant at the base.A photograph looking down a carpeted staircase with a wooden banister and a safety gate at the top landing.
8. Installation of New En-Suite Shower Room & Reconfiguration of Existing Bathroom.
9. Reconfiguration of Existing winding stairs to straight stairs (not seen in this photograph – the stairs go to the Bathroom/Bedroom to the right of this image and are a recent addition to the property).
A photograph of an interior room, likely a bathroom, featuring a window with frosted glass, wooden flooring, and a radiator.A photograph showing an interior staircase with pink floral carpet, white balusters, and a wooden handrail leading to a window.
