Re: PA/17/00136/B - Installation of play equipment, Ellison's Green Cannan Avenue Kirk Michael Isle Of Man
With reference to the above mentioned application, please be advised that there is a 3 inch diameter Distribution Main and a Public Sewer passing through the land of the proposed play area as shown in the attached layout.
We are not writing to object to the application but to inform you that in the event of a distribution problem, Manx Utilities Authority would require access to these services at all times.
No part of the proposed development may be constructed, nor any trees planted within three metres of any service either at the time of construction or any time in the future.
Please also be aware that there may also be buried items and/or mains for which no records exist and therefore are not indicated on the plan.
Notes: In the event of trial holes or other works being required, in order to locate and then subsequently protect or divert the water mains, all associated costs would be the responsibility of owner(s)/applicant(s).
Yours sincerely
Andrew Kneen Projects & Flood Risk Management Assistant
Enc. Plan of site showing location of services
Manx Utilities • PO Box 177 • Douglas • Isle of Man • Italy 1P2 e: [email protected] • t: 01024 967667 • www.manxutilities.im
A technical site plan displaying a drainage assets legend and public sewer lines overlaid on a map of local streets.
The position of the Authority's assets is shown as accurately as possible but the position must be regarded as approximate only. Consequently the Authority is unable to guarantee that any of the information given is correct.
Before any excavation takes place the following has been considered:-
All health and safety procedures.
Asset location for other utilities.
Trial holes or mains marking for MUA Assets
(Any damage WILL result in repair and administration charges).
Marine
Drainage Assets Legend
Live Public Sewers Foul Surface water Combined Transition Overflow Trade Effluent Watercourse Treated Effluent Whey Sewer Unknown Abandoned Public Manhole Private Manhole Underground_Facility Network Fitting
Valid for this enquiry and 21 days from the date of issue only: DATE: 01/03/2017
A black and white topographical map extract showing road networks, building footprints, and blue parking symbols.
Mans Utilities Authority Isle of Man Business Park Douglas, Isle of Man, IM2 2QZ Tel.(01624) 687 687
A location map snippet displaying surrounding streets, property names, and road layouts in a rural setting.
The position of the Authority's assets is shown as accurately as possible but the position must be regarded as approximate only. Consequently the Authority is unable to guarantee that any of the information given is correct.
Before any excavation takes place the following has been considered:-
All health and safety procedures.
Asset location for other utilities.
Trial holes or mains marking for MHA Assets.
(Any damage WILL result in repair and administration charges).
Water Assets Legend
Live Mains
Private Mains
Abandoned Mains
Valve - open or closed
Duct trench
Terminating Hydrant
In-Line Hydrant
Valid for this enquiry and 21 days from the date of issue only: DATE: 01/03/2017
Location Plan {{image:7220019}}
Manx Utilities Authority Isle of Man Business Park Douglas, Isle of Man, IM2 2QZ Tel.(01624) 687 687
